We supply electro galvanized low carbon steel wire for general purpose with specification ranging from ф1.0mm to 6.0mm.

It is used for tying, bundling, weaving and nail-making.
It conforms to the standard YB544-65. This product can also be made in accordance with international standard lSO/DP7989D or to meet the specific requirements of clients.

Features:
1. Tensile strength: 300-400 (N/mm2)
2. Uniform zinc coating: It reaches the level of Group I according to China standard. Currently, Shengyuan is the only factory in the same trade in China that reaches both Group I grade and the international standard ISO/DP7989D.
3. Precise wire diameter
4. The product has bright silver color, even zinc coating with good adhesion and strong corrosion resistance.

Size (mm)

0.90

1.25

1.60

2.00

2.50

3.15

Diameter range (mm)

+/-0.025

+/-0.035

+/-0.045

+/-0.05

+/-0.065

+/-0.08

Tensile strength (N/mm2)

340-500

Elongation (%)

7.5

                       10

Min. Zinc Coating (g/m2)

155

180

195

215

245

255

DC resistence (ohms/km)

216.92

112.45

68.64

43.93

28.11

17.71

Torsion Test (min. Turn)

33

24

37

30

24

19

wire dia.

toler

zinc

tensile

elongation

resistance

coil ID

weight

mm

+/-mm

g/m2

N/mm2

min%

ohm/km

mm

kg/coil

0.90

0.025

>60

340-500

10

216.92

350-450

300-500

1.25

0.035

112.45

1.60

0.045

  68.64

2.00

0.050

 43.93

2.50

0.065

28.11

3.15

0.08

17.71
